220/380V 24V Power supply

€37.60 Tax excl.

Quantity discounts on the category 4.3 Direct power supply

✔ Between 5 and 19 lots purchased: 10% discount

✔ 20 lots and more purchased: 20% discount

☞ Want to become a distributor of our brand?
✉ Contact us for more customised discounts

Power supply in W

60 W 75 W 120 W 240 W 480 W

Combinations	Power supply in W	Reference	Stock	Price	Add to cart
Power supply in W : 60 W Reference : ALM-WDR-060-24 Stock : 0	60 W	ALM-WDR-060-24	Available later	€37.60 Tax excl.	€37.60 Tax excl.
Power supply in W : 75 W Reference : ALM-WDR-075-24 Stock : 0	75 W	ALM-WDR-075-24	Available later	€39.40 Tax excl.	€39.40 Tax excl.
Power supply in W : 120 W Reference : ALM-WDR-120-24 Stock : 0	120 W	ALM-WDR-120-24	Available later	€49.68 Tax excl.	€49.68 Tax excl.
Power supply in W : 240 W Reference : ALM-WDR-240-24 Stock : 0	240 W	ALM-WDR-240-24	Available later	€82.08 Tax excl.	€82.08 Tax excl.
Power supply in W : 480 W Reference : ALM-WDR-480-24 Stock : 0	480 W	ALM-WDR-480-24	Available later	€209.76 Tax excl.	€209.76 Tax excl.

380V DC 24V Power supply

Specifications:

- Power supply 200~500VAC 47Hz~63Hz (282.8~707VDC)
- Output voltage DC 24V
- Voltage setting: ±10%

Reference	Power	Dimension (LxDxH)	Output current	Input current	Packing
ALM-WDR-060-24	60W	3212597mm	5A	0.4A 400V AC - 0.7A 230V AC	0.33kg
ALM-WDR-075-24	75W	3212597mm	6.2A	0.4A 400V AC - 0.7A 230V AC	0.33kg
ALM-WDR-120-24	120W	40125.2113.5mm	5A	0.7A 400V AC - 1.2A 220V AC	0.7kg
ALM-WDR-240-24	240W	63125.2113.5mm	10A	1A 400V AC - 2A 230V AC	0.7kg
ALM-WDR-480-24	480W	85.5125.2128.5mm	20A	1A 400V AC - 2A 230V AC	0.7kg

Availability date: 2025-07-03
